Product Description
The Concealed Rain Shower is a complete shower system with the mixing valve, main water supply piping, and supporting structure concealed within the wall, leaving only the decorative panel and four-way water outlet components visible.
Concealed Rain Shower Features
Precise Temperature Control:
The Concealed Rain Shower utilizes a dual-chamber, heat-balanced thermostatic valve core with a mechanical temperature limiter, offering an adjustable temperature range of 18°C–60°C and a constant temperature accuracy of ±0.8°C. In the event of sudden changes in hot or cold water pressure, it completes temperature compensation and triggers a scalding cutoff in ≤0.5 seconds, making it suitable for both home and commercial use, significantly enhancing safety and continuous shower comfort.
Multi-Function Switching:
The four-way water diversion system supports any combination of overhead, handheld, wall, and bottom spray. The diversion valve core is made of highly wear-resistant ceramic or POM material, with a switching lifespan of ≥2 million cycles. Each channel can be individually limited and locked, facilitating project customization and user-specific configuration.
Wide-area Rain Feeling:
The overhead showerhead offers optimized coverage and is available in sizes of Ø250/300/350/400mm or 200×400mm. Its uniform water flow design delivers a flow rate of 0.25–0.9 L/s/m² per unit area. The adjustable flow grille allows for a variable flow rate, from a gentle drizzle to a powerful curtain of rain, creating a spa-like bathing experience.
Water-saving and Highly Efficient:
The Concealed Rain Shower features a built-in adjustable flow limiter and diverter balancer. The system's total flow rate in standard mode is controlled at 10–14 L/min, while in energy-saving mode it can be reduced to 7–9 L/min. Its flow distribution and booster chamber design reduce water consumption while maintaining excellent water flow, meeting the water conservation requirements of green buildings and hotels.
Corrosion-Resistant and Durable:
The exposed panel and overhead showerhead are made of 304 stainless steel or CW617N brass. The valve body is a lead-free, high-strength copper alloy with a surface treatment using PVD, three-layer electroplating, or nano-coating. Key components have passed a neutral salt spray test for over 120 hours and are made of anti-scaling materials, ensuring long-term moisture, oxidation, and scratch resistance, reducing replacement frequency.
Low-Pressure Compatibility:
Designed to accommodate a wide operating pressure range, with optional built-in pressure stabilization modules or external booster units, this ensures stable overhead showerhead operation and sufficient handheld water pressure even in low-pressure water supply environments, reducing renovation costs for older buildings or remote properties.
Modular Maintenance:
The Concealed Rain Shower utilizes a quick-release panel and modular valve core construction. The concealed valve body is equipped with standardized plug-in connectors. Maintenance requires only removing the panel to replace the core valve core or diverter assembly, eliminating the need for wall penetration. We recommend that universal valve core spare parts and pre-installed box dimensions be managed in batches to significantly reduce after-sales maintenance costs.
Concealed Rain Shower Applications
High-end Private Residential Bathrooms:
The Concealed Rain Shower is suitable for master bathrooms or suites in villas and luxury apartments. Its concealed panel preserves the overall wall lines, and its four-way function meets daily showering, spot rinsing, and soaking needs. Its constant temperature and anti-scalding mechanism enhance home safety, and the panel surface and handle style can be customized to suit the owner's soft furnishing color palette.
Five-Star Hotel Suites:
In luxury hotels, stable constant temperature and wide-range rain feel enhance guest satisfaction. Modular components facilitate quick maintenance and batch replacement, and the flow rate can be set to a water-saving setting based on the hotel's energy management strategy, achieving a balance between experience and operating costs, facilitating unified delivery for chain brands.
Private Rooms in Spas and Wellness Centers:
The Concealed Rain Shower is ideal for spa rooms or treatment cabins requiring a differentiated experience. The combination of an overhead shower, handheld shower, and wall spray allows for transitions from a relaxing rain shower to a spot massage. Its corrosion-resistant materials and easy-to-clean design reduce disinfection and maintenance burdens, improving service consistency and customer repurchase rates.
Model Homes and Finished Delivery Units:
As a highlight of the model homes, the concealed showerhead enhances the sense of space and design aesthetics. It provides panel colors and functional configuration templates, allowing developers to standardize packages within delivery standards and supporting bulk pre-installation and quick replacement of accessories.
Elderly Care and Rehabilitation Facilities:
In nursing homes or rehabilitation centers, constant temperature protection and easy operation are crucial. The four functions can be configured in barrier-free modes. The concealed design reduces collision risk and facilitates daily cleaning and disinfection, improving care efficiency and safety.
Projects and Distribution Channels:
The Concealed Rain Shower is suitable for building finish packages, residential developments, and dealer channels. It supports OEM labeling and comes with a complete embedded box dimension chart, installation manual, and maintenance plan. This facilitates project-based procurement, bidding, and long-term spare parts supply chain management, reducing project delivery risks.
